Hikvision DS-2CE16D9T-AIRAZH 2 MP Motorized Varifocal Bullet Camera

Analog Camera, CCTV

Hikvision DS-2CE16D9T-AIRAZH 2 MP Motorized Varifocal Bullet Camera

Image Settings: HSBLC, Digital noise reduction, Digital Zoom (62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM, LSC (Lens Shading Correction)
Frame Rate1080P@25/30fps.
Day/Night Mode Color/BW/EXT
Wide Dynamic Range (WDR): 120 dB
SNR>62dB.
Image Enhancement BLC
Privacy Mask On/Off, maximum 8 zones

About HIKVISION DS-2CE16D9T-AIRAZH

3D DNR technology delivers clean and sharp images
5 mm to 50 mm motorized varifocal lens focuses automatically when zooming in or out
Up to 120 m IR distance for bright night imaging
Water and dust resistant (IP67)
Dual outputs (HDTVI and CVBS signals output simultaneously)
Transmits both HD video and power over the same coaxial cable
Heater is available with 24 VAC

Lens
Lens Type Angle of view: 59.8°-6.2°

Image Settings HSBLC, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM, LSC (Lens Shading Correction)
Frame Rate1080P@25/30fps
Day/Night Mode Color/BW/EXT
Wide Dynamic Range (WDR)120dB
SNR>62dB
Image Enhancement BLC
Privacy MaskOn/Off, maximum 8 zones
White Balance ATW/ AWC-SET/ Manual
AGC Support

Hikvision DS-2CE16D9T-AIRAZH Surveillance camera Specifications | Hikvision Surveillance cameras

Interface
Video Output TVI&CVBS

Event
Motion Detection On/Off, maximum 4 zones
General
Dimension313.5×100.8×107.3mm
Weight1650g
Operating Condition-40 °C – 60 °C (-40 °F – 140 °F), Humidity 90% or less (non-condensing)
Communication Up the coax, Protocol: Pelco-C(CVBS output), HIKVISION-C(TVI output)
Language Chinese/ English
Power SupplyAC24V±15%/ DC12V±15%, Heater is available with 24VAC only
Consumption Max. 20W
IR Range Up to 120m

Camera
Image Sensor:		2MP CMOS Image Sensor
Signal System:		PAL/NTSC
Effective Pixels:		1944(H)×1092(V)
Min. Illumination:		0.01Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time:		1/25 (1/30) s to 1/50,000 s
Lens:		5-50mm motorized VF lens, Angle of view: 59.8°–6.2°
Adjustment Range:		Pan: 0–360°, Tilt: 0–90°, Rotation: 0–360°
Day& Night:		IR cut filter with auto switch
Wide Dynamic Range:		120dB
Video Frame Rate:		1080p@25fps/1080p@30fps
HD Video Output:		1 Analog HD output
Synchronization:		Internal Synchronization
CVBS Output:		1Vp-p Composite Output (75Ω/BNC)
S/N Ratio:		More than 62 dB
Up the Coax:		Support

Categories: Analog Camera, CCTV

Additional information

Brand	Hikvision
